High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system

Brand Name : CHCNAV

Model Number : T12 Pro rover+B5 base

Place of Origin : China

MOQ : 1 piece

Price : $4,500.00

Payment Terms : L/C, T/T

Supply Ability : 1 ~ 30 day

Delivery Time : 30 work day

Product name : RTK receiver

Frequency : 1408 channels

GPS : L1C/A,L1C,L2C,L2P,L5

Galileo : E1, E5A, E5B, E5AltBOC, E6

QZSS : L1C/A, L1C, L2C, L2E, L5

BDS : B1, B2, B3

Working range : 5km typical, 8~10km optimal

Application : full-wave

Transmitting power : 0.5W, 1W, 2W adjustable

Contact Now

Product Paramenters
T12 pro rover
Satellite tracking
Satellite system
GPS+BDS+Glonass+Galileo+QZSS,
Support the Beidou three generations, support Five Star 21 frequency point
Satellite tracking
BDS: B1I,B2I,B3I,B1C,B2a,B2b*
GPS: L1C/A,L1C,L2C,L2P,L5
GLONASS: G1,G2,G3
Galileo: E1,E5a,E5b,E6*
QZSS: L1C/A,L1C,L2C,L5
IRNSS: L5*
SBAS: L1C/A*
Number of channels
1408
Initialization reliability
99.99%
Satellite-based differential (optional)
Can work without a network
signal capture sensitivity
Typical value - 162dbm, stronger ability to capture weak signals
No network continuous test
Support
Accuracy
static precision
Plane accuracy: ±(2.5mm+0.5×10-6 ×D)mm
Height accuracy: ±( 5mm+0.5×10 -6 ×D)mm
RTK accuracy
Plane accuracy: ±( 8mm+1×10 -6 ×D)mm
Height accuracy: ±(15mm+1×10 -6 ×D)mm
Tilt measurement accuracy
8mm+0.3 mm/° tilt
Real-world measurement accuracy
typically 2~4cm, measuring distance 2~15 meters
GNSS+Inertial navigation
IMU update
200Hz
rate tilt angle
0-60°
User interaction
LCD screen
Quasi-retina screen, color high-definition 1.1-inch OLED
resolution: 126*294 can be
seen clearly and brightly even under direct sunlight
LED
1 satellite light + 1 differential data light
button
Fn function key + power/confirmation key
web page
supports PC/mobile web pages
Camera
Pixel
2MP&5MP
Frame
25Hz
Rate Field of View
75°
Illumination
Starlight camera, OmniPixel3-GS technology to maintain
full-color images under 0.01lux illumination
Special feature
Video measurement, efficiency increased by 60%

3D modeling, internal and external efficiency doubled

AR real-time navigation, put the point without getting

lost, visual stakeout, put it in place with one shot
Physical characteristics
Size
Φ152 mm*81 mm
Weight
1.06Kg
Material
Magnesium alloy
Working temperature
-45℃~+75℃
Storage temperature
-55℃~+85℃
waterproof breathable membrane
Prevent water vapor from entering the device in harsh environments such as
sun exposure and sudden heavy rain
Waterproof and dustproof
IP68
Anti-collision
IK08
B5 base
project
content
parameter
Receiver characteristics
satellite tracking
GPS+BDS+Glonass+galileo+QZSS, support Beidou third-generation satellites, support five-star sixteen-frequency
operating system
LINUX operating system
number of channels
1408 channels
Initialization time
<5s (typ.)
Initialize reliability
>99.99%
Receiver appearance
button
1 dynamic/static switch key, 1 power key
indicator light
1 differential signal light, 1 satellite light, 1 static data acquisition light, 1 power light
Nominal accuracy
static precision
Plane accuracy: ±(2.5+ 0.5×10-6×D) mm
Elevation accuracy: ±(5+0.5×10-6×D) mm
RTK accuracy
Plane Accuracy: ±(8 + 1×10-6×D) mm
Elevation accuracy: ±(15+ 1×10-6×D) mm
Stand-alone accuracy
1.5m
Code differential accuracy
Plane Accuracy: ±(0.25 + 1×10-6×D) m
Elevation accuracy: ±(0.5+ 1×10-6×D) m
GNSS+Inertial Navigation
IMU
200Hz
slope
0~60°
Tilt compensation accuracy
10mm+0.7mm/°tilt (accuracy within 30°<2.5cm)
Electrification parameters
Battery
Built-in 6800mAh lithium battery, support 15 hours battery life of mobile station
External power supply
Support external power supply via USB port
physical properties
Size (L*W*H)
119mm*119mm*85mm
weight
0.73kg
Material
Magnesium alloy AZ91D body
Operating temperature
-45℃~+75℃
storage temperature
-55℃~+85℃
Waterproof and dustproof
IP68 class
shock shock
IK08 class
Anti-drop
Resist 2 meters free fall
data output
output format
NMEA 0183, binary code
output method
BT/Wi-Fi/Radio
static storage
storage format
Can directly record HCN, HRC, RINEX
storage
Standard 8GB built-in storage
Download method
Universal USB data download; HTTP download
data communication
I/O interface
1 external UHF antenna port
1 USB-TypeC interface, support charging, power supply, data download
network module
Handbook supports 4G full Netcom
Radio station
Built-in high frequency 450-470MHz single receiver radio
protocol
CTI protocol, transparent transmission, TT450
Blue tooth
BT4.0, backward compatible with BT2.x, compatible with Windows, Android, IOS systems
data transmission
Wi-Fi data link
Wi-Fi
802.11 b/g/n
NFC
Support NFC flash connection
Receiver function
super double
Support radio + network two-way data differential at the same time, provide comprehensive data services
One-click match
Support handbook software to match base station data with one key
Remote upgrade
Support one-key remote upgrade
Handbook parameters
model
HCE600 Android Measurement Handbook
The internet
4G full Netcom, built-in eSIM for three years of surveying and mapping traffic
operating system
Android 10
CPU
Octa-core 2.0Ghz processor
LCD screen
5.5'' HD display
Battery
14 hours of battery life
Waterproof and dustproof
IP68
Product features
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
certificateHigh precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
Certifications

High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system
Company Profile
High precision chc t12 pro rover and B5 base land survey chc t12 pro and ibase Gnss receiver Gps Rtk system

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
